Category Specification Engine Engine Make & Model Perkins 404J-E22TA (Turbo) Gross Horsepower 67 hp (50.0 kW) Net Horsepower 64 hp (47.7 kW) Peak Torque 208 Nm @ 1800 rpm Displacement 2.2 L Emissions Compliance Tier 4 Final / EU Stage V Performance Rated Operating Capacity 1,750 lb (790 kg) Tipping Load 3,500 lb (1,588 kg) ROC with Counterweights 1,840 lb (835 kg) Breakout Force (Lift) 17.0 kN Breakout Force (Bucket) 32.3 kN Hydraulics Standard Flow 20.6 gpm (78.0 L/min) @ 3,050 psi (210 bar) High Flow (Optional) 30.7 gpm (116.2 L/min) @ 3,050 psi (210 bar) Dimensions Height to Hinge Pin 3,099 mm Overall Height 1,974 mm Length without Attachment 2,685 mm Length with Bucket 3,305 mm Overall Width 1,642 mm Wheelbase 1,128 mm Ground Clearance 178 mm Dump Height 2,470 mm Dump Reach @ Max Height 542 mm Dump Angle 40° Rollback Angle (Ground) 32° Departure Angle 23° Weights Operating Weight 2,842 kg Shipping Weight 2,705 kg Travel Speeds Low Range 11.9 km/h High Range (Optional) 18.5 km/h Fuel & Service Fuel Tank Capacity 73.8 L Hydraulic Reservoir 18.9 L Hydraulic System Capacity 32.2 L Standard Features Lift Geometry Radial ROPS/FOPS Level 1 Included Manual Attachment Coupler Included LED Work Lights 2 front, 2 side, 2 rear CASE SiteWatch™ Telematics 5-year subscription Optional Features High-Flow Hydraulics 30.7 gpm (116.2 L/min) Hydraulic Attachment Coupler Available Electro-Hydraulic Controls Available Deluxe Air Suspension Seat Heated with lumbar support 8-inch LCD Display Available Ride Control Available Creep Speed Mode Available
