Category Specification Engine Engine Model Perkins 404F-E22T Power 49 hp (36.3 kW) @ 2800 rpm Torque 122 lb-ft (165 Nm) @ 1800 rpm Displacement 2.2 L Emissions Standard Tier 4 Final (No DEF or DPF required) Transmission Type Hydrostatic (Danfoss / Rexroth) Max Speed 7.5 km/h (4.6 mph) forward and reverse Dimensions Operating Weight 4262 kg (fixed dipper), 4342 kg (extending dipper) Length 3.57 m Width 1.8 m Height 2.2 m (fixed dipper), 2.27 m (extending dipper) Ground Clearance 260 mm Backhoe Performance Max Dig Depth 2.55 m (fixed dipper), 3.08 m (extending dipper) Max Reach at Ground 3.38 m (fixed), 3.91 m (extended) Max Load Over Height 2.35 m (fixed), 2.67 m (extended) Bucket Rotation 202° (fixed), 180° (extended) Bucket Tearout Force 21.6 kN (4852 lbf) Dipper Tearout Force 14.6 kN (3280 lbf) Loader Performance Max Dump Height 2.21 m Load Over Height 2.65 m Loader Hinge Pin Height 2.86 m Bucket Capacity 0.37 m³ (general purpose) Breakout Force (Bucket) 23.0 kN (5180 lbf) Breakout Force (Arms) 23.5 kN (5291 lbf) Rated Operating Capacity 665 kg (1466 lb) Tipping Load 1900 kg (4188 lb) Hydraulics Pump Type Gear pump Standard Flow 45 L/min (11.8 gpm) High Flow (Optional) 100 L/min (26.4 gpm) System Pressure 207 bar (3002 psi) manual, 220 bar (3190 psi) with EasyControls Fuel & Fluids Fuel Tank Capacity 45 L (11.8 gal) Hydraulic System 45 L (11.8 gal) Engine Oil 9.6 L (2.5 gal) Cooling System 8 L (2.1 gal) Chain Cases 10 L (2.6 gal) Electrical System Voltage 12 V Battery 72 Ah Alternator 50 A (standard), 85 A (with A/C option) Operator Environment Cab Type Fully glazed ROPS/FOPS with heater and A/C Noise Level (Internal) 82 dB(A) Noise Level (External) 101 dB(A) Vibration (Whole Body) 0.29 m/s² Vibration (Hand Arm) ≤ 2.5 m/s² (except rough tracking: 3.4 m/s²)
