Category Specification Engine Model V3307-CR-TE4 Emission Certification Tier 4 Gross Horsepower 74.3 HP (55.4 kW) Net Horsepower 71.6 HP (53.4 kW) Displacement 203.3 cu in (3331 cc) Cylinders 4 Bore x Stroke 3.8 in × 4.8 in (94 mm × 120 mm) Aspiration Turbocharged Rated Speed 2600 RPM Low Idling Speed 1250 RPM Peak Torque 192 ft-lb (260.3 N·m) Compression Ratio 15.6:1 Firing Order 1-3-4-2 Performance Rated Operating Capacity 2690 lbs (1220 kg) Tipping Load 5380 lbs (2440 kg) Bucket Breakout Force 5884 lbf (2669 kgf) Lift Arm Breakout Force 4850 lbf (2200 kgf) Traction Force 8494 lbs (3853 kg) Lift Arm Path Vertical Hydraulics Standard Hydraulic Flow 20.9 GPM (79.0 LPM) High Flow Option 30.4 GPM (115.0 LPM) Hydraulic Pressure 3271 psi (225.5 bar) Hydraulic Tank Capacity 4.2 gal (16.0 L) Hydraulic System Capacity 9.25 gal (35 L) Capacities Fuel Tank 26.9 gal (102.0 L) Engine Oil Capacity 3.1 gal (11.8 L) Coolant Capacity 3.7 gal (14.0 L) Radiator 1.8 gal (6.8 L) Cooling Fluid Recovery Tank 0.5 gal (2.0 L) Battery Capacity 12V RC: 160 min, CCA: 900A Dimensions & Weight Operating Weight 8245–8466 lbs (3740–3840 kg) Overall Height 81.3 in (2065 mm) Overall Width 71.8 in (1823 mm) over wheels; 75 in (1905 mm) with standard bucket Overall Length 115.0 in (2920 mm) without bucket; 144.1 in (3660 mm) with bucket Height to Hinge Pin 128.3 in (3258 mm) Reach at Max Height 36.9 in (936 mm) Dump Height 98.0 in (2490 mm) Dump Reach 36.9 in (936 mm) Ground Clearance 8.1 in (207 mm) Dump Angle 43° Rollback Angle 27° Departure Angle 25° Wheelbase 44.3 in (1125 mm) Turning Radius (rear) 53.7 in (1364 mm) Drive & Tires Travel Speed (Low/High) 7.4 mph (11.9 km/h) / 11.8 mph (19.0 km/h) Tire Size 12-16.5-10PR
