Category Specification Model Caterpillar 259D Engine Model CAT C3.3B DIT (Turbocharged) Emissions Tier 4 Final / EU Stage IV Net Power 73.2 HP (54.6 kW) Gross Power 74.3 HP (55.4 kW) Displacement 3.3 L (203 in³) Rated Operating Capacity 2,900 lb (1,315 kg) with counterweight Rated Operating Capacity (35%) 2,010 lb (912 kg) Tipping Load 5,750 lb (2,610 kg) Operating Weight 8,945 lb (4,057 kg) Hydraulic Flow – Standard 20 GPM (76 L/min) Hydraulic Flow – High Flow 30 GPM (113 L/min) @ 3,335 psi (23,000 kPa) Fuel Tank Capacity 24.8 gal (94 L) Cooling System Capacity 3.7 gal (14 L) Hydraulic System Capacity 13.2 gal (50 L) Travel Speed – Low 5.1 mph (8.2 km/h) Travel Speed – High (optional) 8.4 mph (13.5 km/h) Track Width 12.6 in (320 mm) Ground Pressure 4.6 psi (31.7 kPa) Lift Arm Type Vertical Lift Standard Bucket Width 68 in (1,727 mm) Bucket Capacity 0.44 – 0.48 yd³ (0.34 – 0.37 m³) Length with Bucket 134.9 in (3,426 mm) Length without Bucket 106 in (2,692 mm) Width Over Tracks 66 in (1,676 mm) Height to Top of Cab 83.1 in (2,111 mm) Max Lift Height (Hinge Pin) 119 in (3,023 mm) Dump Angle at Max Height 52° Dump Reach at Max Height 23 in (584 mm) Ground Clearance 8.9 in (226 mm) Departure Angle 35° Turning Radius (rear) 58.9 in (1,496 mm)
