Category Specification Engine Model EcoMAX TCAE-55 Type 4-cylinder, turbocharged diesel Emissions Tier 4 Final (EPA-T4F / EU Stage IIIB) Displacement 268.5 cu in (4.4 L) Gross Power 74 hp (55.2 kW) @ 2400 rpm Max Torque 295.1 lb-ft (400 Nm) @ 1200 rpm Cooling System Water-cooled Starter Motor 4.2 kW Alternator 95 amps Battery 12 V Dimensions Length (w/o attachment) 9.91 ft (3.02 m) Width Over Tracks 6.57 ft (2.00 m) Height to Top of Cab 6.89 ft (2.10 m) Ground Clearance 9.38 in (238 mm) Wheelbase 6.89 ft (2.10 m) Dump Angle 42° Rollback Angle @ Ground 30° Max Rollback Angle 94° Dig Depth 3 ft (0.91 m) below ground Performance Rated Operating Capacity (retracted) 3,695 lb (1,676 kg) Rated Operating Capacity (extended) 1,614 lb (732 kg) Lift Height 13 ft 3 in (4.03 m) Forward Reach 8 ft (2.44 m) Max Discharge Height 10.5 ft (3.2 m) Travel Speed 6.4 mph (10.3 km/h) Hydraulics Standard Flow 24 GPM (90 L/min) High Flow (optional) 33 GPM (125 L/min) Main Relief Pressure 3,335 psi (22,994 kPa) Hydraulic System Capacity 14.6 gal (55 L) Capacities Fuel Tank 27.3 gal (103 L) Engine Oil 3.7 gal (14 L) Cooling System 5.9 gal (22 L) Weights Operating Weight (ROPS canopy) 12,482.6 lb (5,662 kg) Operating Weight (Cab) 12,614.9 lb (5,722 kg)
